12V/24V Good Supplier Micro DC Gear Motor

Basic Info

Model NO.	GF-555
Structure and Working Principle	Brush
Certification	Ce
Brand	Derry
Voltage	12/24V
Usage	Home Appliance
Package	Standard Export Carton
Current	140mA
No-Load Speed	3000rpm
Transport Package	CTN
Specification	CE
Trademark	Derry
Origin	China, Zhejiang
HS Code	8501109990
Production Capacity	30000PCS/Month

Product Description

Model: GF-555
We can design it according to your special requirements.
Gear box Data:

Number of stages	Stages reduction	Stages reduction	Stages reduction	Stages reduction	Stages reduction
Reduction ratio	127	251	389, 590, 722, 897	624, 830, 1166	3385, 5078
Max. Running torque	30kgf.cm	30kgf.cm	50kgf.cm	80kgf.cm	100kgf.cm
Max. Gear breaking torque	90kgf.cm	90kgf.cm	150kgf.cm	240kgf.cm	300kgf.cm
Max. Gearing efficiency	73%	65%	65%	59%	53%

Motor data:

Type	RatedVotageV	No load		Load Torque				Stall torque
		Current	Speed	Current	Speed	Torque	Outputpower	Torque	Current
		mA	rpm	mA	Rpm	gf.cm	W	gf.cm	MA
GF-555-123000	12	≤140	3000	≤800	2200	150	3.3	600	3000
GF-555-124500	12	≤220	4500	≤1200	3300	220	7.2	880	4800
GF-555-126000	12	≤350	6000	≤2000	4500	300	13.5	1200	6000
GF-555-243000	24	≤70	3000	≤400	2200	150	3.3	600	1600
GF-555-244500	24	≤110	4500	≤600	3300	220	7.2	880	3000
GF-555-246000	24	≤180	6000	≤1000	4500	300	13.5	1200	4000

2.Production Flow

3.Company Information
In recent ten years, Derry has been dedicated to the manufacture of the motor products and the main products can be classified into the following series, namely DC motor, DC gear motor, AC motor, AC gear motor, Stepper motor, Stepper gear motor, Servo motor and Linear actuator series.

Our motor products are widely applied in the fields of aerospace industry, automotive industry, financial equipment, household appliance, industrial automation and robotics, medical equipment, office equipment, packing machinery and transmission industry, offering customers reliable tailored solutions for driving and controlling.



4.Our Services
1). General Service:

Quick Reply	All enquiry or email be replied in 12 hours, no delay for your business.
Professional Team	Questions about products will be replied professionally, exactly, best advice to you.
Short Lead time	Sample or small order sent in 7-15 days, bulk or customized order about 30 days.
Payment Choice	T/T, Western Union,, L/C, etc, easy for your business.
Before shipment	Take photos, send to customers for confirmation. Only confirmed, can be shipped out.
Language Choice	Besides English, you can use your own language by email, then we can translate it.

2). Customization Service:
Motor specification(no-load speed , voltage, torque , diameter, noise, life, testing) and shaft length can be tailor-made according to customer's requirements.



5.Package & Shipping
