Low vibration 2.3A Rated Current Stepping servo motor for Chemical analyzer

Basic Info

Model NO.	17SSM
Operate Mode	Operate with a Motor Drive
Type	Electromechanical
Certification	ISO9001, CE
Brand	Baolong
RatedCurrent(A)	2.3
Step Angle (°)	1.8
Encoder Resolution	2500
Line Driver Output	3-channel:A+A-B+B-Z+Z-
Lead Wire	4
Maximum speed	3600
Allowable axial load (N)	Motor weight below
Transport Package	Carton with Inner Foam Box; Pallet
Specification	CE, Rohs, SGS
Trademark	BAOLONG
Origin	Jiangsu Changzhou
HS Code	8501109990
Production Capacity	1200000 PCS/Year

Product Description

Product Description
Stepping servo motorStep-Servo System are specifically designed to be paired with Step-Servo Motor to create motor and drive combinations that outperform traditional step motor systems. Each Step-Servo motor is a premium, two-phase, hybrid step motor built with an integral high resolution feedback device. The performance gains achieved when using a Step-Servo motor in combination with one of our Step-Servo drives include high peak torque ranges for faster acceleration and greater machine throughput, as well as quieter operation and less power consumption. Description of drive system of SS series
SS series is a high-performance, intelligent stepping servo drive system. The servo control technology is integrated into the stepping system to achieve closed-loop control, creating excellent performance that is difficult to achieve in the open loop system. The latest 32-bit DSP digital processing technology is adopted. The driver control algorithm adopts advanced servo control algorithm and FOC control technology. The driver has low heat, low motor vibration and stable operation. The user can set any subdivision within 200~25600 and any current value within the rated current, which can meet the application needs of most occasions. Drive characteristics of SS series
New 32-bit DSP technology16 subdivision optionsServo control algorithm, accurate speed and position control, and good responsivenessAdjust the current according to the load in real time to minimize the heatingAutomatically match motor parameters and optimize current controlPulse+direction/CW+CCW1MHz digital signal filterSelf inspection mode: the motor moves in forward and reverse direction repeatedly at the speed of 180RPM

Product Parameters

SeriesModel	RatedCurrent(A)	PhaseResistance(Ω)	PhaseInductance(mH)	LeadWire(No.)	HoldingTorque(N.cm)	MotorLength L(mm)	RotorInertia(g.cm²)	MotorWeight(g)	StepAngle(°)
17SSM3403EG	2.3	0.7	2.3	4	30	37	35	170	1.8
17SSM8403EG	2.3	1.0	1.9		50	51	77	420
17SSM6403EG	2.3	1.4	3.1		80	67	115	530
Encoder Resolution		2500			Line Driver Output		3-channel:A+A-B+B-Z+Z-

Model	Match drive	Static moment	Rotor inertia	Encoder resolution	Maximum speed	Installation dimensions	Allowable suspended load (N)					Allowable axial load (N)
		Nm	gcm2	Pulse/cycle	RPM	mm	Distance from shaft end (mm)
11SSM3413	SS5	0.065	8	2500	3600	28	20	25	34	52	-	Motor weight below
11SSM4413		0.08	11
11SSM5413		0.12	14
14HSM3418	SS5	0.2	18			35	20	25	34	52	-
14HSM5418		0.35	22
17SSM3403	SS5	0.3	35			42	35	44	58	85	-
17SSM8403		0.5	77
17SSM6403		0.8	115
23HSM6404	SS5	1.1	280			57	63	75	95	130	190
23HSM80404		2.2	480
23HSM1460	SS9	2.5	680
24HSM4442	SS5	0.9	200			60	90	100	130	180	270
24HSM6442		1.6	350
23HSM1456	SS9	2.8	780
34HSM8402	SS9	4.2	1050			86	260	290	340	390	480
34HSM4402		8.2	1800
34HSM5402		12	2500
